Cubic Evaporators
Efficient heat transfer and easy installation
Our cubic air coolers offer optimum cooling performance for a wide range of applications. Whether in supermarkets, warehouses, halls or slaughterhouses: robustness, high flexibility and individual adaptation options to specific requirements allow the cubic air coolers to master even demanding cooling tasks. This ensures the best possible product quality at all times. The design also enables easy installation, maintenance and cleaning, so that with our cubic air coolers you are also well equipped in terms of hygiene regulations.
Commercial cubic type evaporating unit, with built-in control valves, for high, positive and negative temperature cold rooms, built in galvanized steel structure with polyester paint. Other bodywork can be done according to customer request.
Commercial Series
- 400V 3N 50Hz power supply. Available in 60 Hz. Other voltages on request.
- High efficiency coils, in copper pipes and aluminium fins, with 4 or 6 mm fin spacing.
- Solenoid valve in liquid line and adjustable thermostatic expansion valve integrated in the unit.
- Electrical or Air defrost.
- Axial motor fans with high air flow.
- Ready-to-solder refrigeration connections, with built-in suction trap.
- Flexible drain pipe heater (for BJC models).
- Aluminium hinged condensate tray.
Industrial Series
- 400V 3N 50Hz power supply. Available in 60 Hz. Other voltages on request.
- Air defrost.
- Air-cooled high efficiency coils, in copper pipes and aluminium fins, with 4, 5, 7 and 10 mm fin spacing.
- Double stainless steel draining pan and insulation for negative temperature.
- Built-in solenoid valve in liquid line and thermostatic expansion valve.
- High-flow axial motor fans operating at 1300 rpm.
- Ready-to-solder refrigeration connections, with built-in suction oil trap.
- Flexible drain pipe heater (only for negative temperature models).
- Defrosting by imbricated heating elements.
- Hot glycol defrosting.
- Anti-corrosion coating of coil.
Industrial NH3 Series
Industrial evaporators for large cold rooms with direct expansion of ammonia, built in galvanized sheet steel bodywork with polyester coating or stainless steel.
- Low ammonia charge.
- Large surface area coils.
- Easy installation.
Ammonia dry expansion
Evaporators designed to work with ammonia in direct expansion, with refrigerant distribution capillaries and suction manifold. The special tube geometry of the industrial evaporators reduces frost formation and allows spacing of defrost cycles. The counter-current circuit design facilitates gas reheating. Thanks to the ammonia-miscible oil, oil return to the compressor occurs naturally during operation.
